On October 22, 2018, Royale Energy and California Resources Corporation (CRC) announced that the two companies had entered into a new joint venture agreement to develop wells throughout the Rio Vista field, the biggest gas field in California. The joint venture agreement was to drill and develop multiple, stacked productive formations in this prolific and historic property.

The agreement expanded the joint venture development area to the entire Rio Vista field. Royale has access to a larger area, more formations and significantly larger reservoirs to drill lower risk infill development wells than had been available under the prior agreement.  Royale’s ability to drill low risk underdeveloped reserves has increased substantially in a very prolific, undeveloped gas field.

Royale evaluates drilling, development wells that target Eocene and/or Upper Cretaceous-age strata in the Eastern part of the field plus the Capay, Midland Sand and Mokelumne River formations in each well.  Target depths are between 4,000 and 7,200 ft.  Initial production rates are expected to range between 1,500 MCF to 2,000 MCF per day, with potential for wells with reserves of several billion cubit feet (BCF).

To date, Royale has drilled twelve commercially productive Rio Vista wells in the Capay, Martinez and McCormack formations with the original agreement.  Royale has an opportunity to evaluate drill locations through 2022.

The Rio Vista field was discovered in 1936 and had produced approximately 4 trillion cubic ft. from more than 15 stacked reservoirs.

Royale purchased the Jameson North assets from General Electric (GE) in December 2018 as they were divesting their oil and gas assets. Royale has identified approximately 20 high quality infill Development well prospects using a 3D seismic survey covering all of our Jameson North Field (JNF) lease ownership in the Permian Basin.

Located in the Permian Basin near Colorado City, the JNF was an extension of the large Jameson Field. The JNF was developed by Shell and Sun Oil in two phases, 1953-58 and 1978-84, as a Strawn Sand and Carbonate Reef play.

Strawn Sands have high porosity of 18-24% and moderate permeability of 150 to 300 md (marine sand). The Strawn has an average 81,000 barrels of oil and 230,000 MCF of reserves per well and they initially produce an average of 85 barrels per day of oil and 215 MCF per day of natural gas.

JNF has additional potential in the Odom Formation with 52,000 barrels of oil and 200,000 MCF of total reserves per well. The Odom produces initially at a rate of 71 barrels of oil per day and 136 MCFD per well.

Additionally, the deeper Ellenburger Formation is productive at a depth of approximately 7,000 ft. Productive Ellenburger wells averaged 70,000 barrels of oil and 65,000 MCF of natural gas per well.

The infill well drilling potential in JNF has been identified by thorough historic well review and from the use of modern seismic data. The 3D seismic survey identified infill drilling opportunities that exist between productive wells in the field. The use of modern seismic data is frequently used to help delineate new drill opportunities in older fields. The data was processed with pre-stack time migration and careful oversight of processing velocities. Proprietary high-resolution post-stack enhancement was used to produce vertical resolution that was tied directly to well logs.

Our results in 2020 drilling have been encouraging. McCabe VT #61, the first well drilled by Royale Energy in JNF in February 2020, encountered very good quality oil-bearing sands in the Strawn. The VT McCabe 62 was drilled as an in-fill evaluation of the Odom, Ellenburger and to further evaluate the Strawn as a completion option.
